Cablelok D10 9.0 - 11.0mm x1
Art.-No. 857-50243
| CABLELOK-D10-01
|
Details
- Cable range 9.0 - 11.0mm
- Supplied in multiples of 1 and 10
- Supplied with installation lubricant sachets
More products in this product group:
| Cable ∅ max | 11.0mm |
| Cable ∅ min | 9.0mm |
| Colour | Black (BK) |
| Content |
1 x CABLELOK-D10 1 x Lubricating Wipes |
| Material | Chloroprene Rubber (CR) |
| PART DESCRIPTION | CABLELOK-D10-01 |
| Pack Cont. | 1 |
| Package Content packed in | bag |
| Port | D |
| Product Description | HellermannTyton’s patented Cablelok mechanical seal enables fast safe cable installation, providing a highly repeatable and consistent seal between the cable and the closure port with excellent non-leak performance. Tested to in excess of 6m head of water, the Cablelok does not rely on the skill and experience of the engineer to achieve the required seal, whilst installation times are typically reduced by up to 90%. |
| Product Family | Cablelok |
| Product Group | D Port Cablelok |
| Short Description | Cablelok D10 9.0 - 11.0mm x1 |
| Technical Description | The D10 Port Cablelok is a mechanical seal manufactured from external grade flexible polychloroprene. The Cablelok is designed for use with duct or cable with a diameter of 9 - 11mm. |
| Type | CABLELOK-D10-01 |
