FRBU 9 port A length closure with 6 x Hellapon Medium 3A Stacked Trays
Art.-No. 857-00630 | FRBTB-AXXNB6X | Details

Distributors near you

More products in this product group:

Colour	Black (BK)
Content	FRBU 9 Port Base A-Length Cover (Dome) Quick Release Clamp Sealing ’O’ Ring 6 x Hellapon Medium Stacked Trays Tray Support Frame Anchor Fixing Kit (2) Tray Tool Transportation Tubing Hook and Loop Management Ties Cable Ties Isopropyl Alcohol Wipes Desiccant Installation Guide Marker Kit Red Marker 1 - 12 Green Marker 1 – 12
Cover Type	A
Material	Polypropylene (PP)
Method of Sealing	Cablelok, Heatshrink
PART DESCRIPTION	FRBTB-AXXNB6X
Pack Cont.	1Set
Package Content packed in	kit
Port	L, B, R
Port count	1, 4, 4
Product Family	A Length
Product Group	FRBU 9 Port Closure
Qty Trays	6
Short Description	FRBU 9 port A length closure with 6 x Hellapon Medium 3A Stacked Trays
Splice Capacity	72
Technical Description	The FRBU 9 Port A Length closure is supplied with a Polypropylene base. The base configuration of 8 round ports and 1 oval port covers a cable diameter range of 1.7 – 20.0mm when using Cablelok mechanical seals and 6.0 – 24.0mm when using heatshrink. The mounting system is manufactured from Grade 304 stainless steel and is supplied with 6 x Hellapon Medium Stacked Trays giving a maximum of 72 fibre splices. The tubed closure and the position of the mounting system allows for ease of access and traceability of the fibre on to the trays. The trays are white which makes it easy to see the colour of the fibre elements as they are routed through the fibre management system and on to the trays
Type	FRBTB-AXXNB6X
Type of Tray	Hellapon Medium
Variant	Outdoor Enclosure
