LC Fibre Panels
Art.-No. 855-00221 | FBPDBKL-LCMMDX-24VF1 | Details

Distributors near you

More products in this product group:

Colour	Black (BK)
Connector Type	LC Duplex
Local order number	FBPDBKL-LCMMDX-24VF1
PART DESCRIPTION	FBPDBKL-LCMMDX-24VF1
Performance Category	Multimode
Port count	48
Product Description	The LC Multimode Fibre Panel is a 1U 19” sliding drawer panel with 24 vertical slots which accept either LC Quad or LC Duplex Adaptors. The panel is supplied pre-loaded with the LC adaptors and any unused slots are fitted with blanks and each fibre port is individually numbered for easy identification.
Product Family	1U 48 Fibre Multimode Panel
Product Group	LC Fibre Panels
Technical Description	The LC Multimode Fibre Panel presents up to a maximum of 96 LC fibres (using LC Quad Adaptors) in 1U of space. The 1U sliding drawer can be locked into position using two simple to operate catches. When fully extended the drawer is designed to lower to 45° giving access to the panel. The drawer can also be locked to a lower maximum of 10°, providing the perfect working platform during installation and maintenance, by sliding the drawer sideways. The rear drawer offers a number of cable options including 4 x 10mm and 2 x 20mm gland holes and has an open section in the centre for specialist cables and patch leads. In addition the base of the tray has cable securing points and cable management holes for securing Fibre Optic Management (FOM). Adjustable mounting ears allow the panel to be positioned within the rack or frame.
Type	FBPDBKL-LCMMDX-24VF1
